ABS Flanged Pressure Gauge PAGN-P-40-1M-G14 8037006 GTIN4052568430160

Name: ABS Flanged Pressure Gauge PAGNP401MG14 8037006 GTIN4052568430160
Brand: FESTO
Price: 1 USD

Quality ABS Flanged Pressure Gauge PAGN-P-40-1M-G14 8037006 GTIN4052568430160 for sale

Brand Name : FESTO

Model Number : PAGN-P-40-1M-G14

Place of Origin : China

MOQ : 1pc

Price : EXW USD20-30

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 pcs per month

Delivery Time : 7-10working days

Packaging Details : Plastic bag, Carton

Type : PAGN-P-40-1M-G14

Part no : 8037006

Brand : FESTO

Degree of protection : IP43

Material housing : ABS

Weight : 80 g

Contact Now

FESTO Flanged pressure gauge PAGN-P-40-1M-G14 8037006 GTIN4052568430160

About product

1.Designs based on EN 837-1.

2.Display units bar, psi, MPa.

3.Design: Bourdon tube pressure gauge.

4.Type of mounting:Front panel mounting.

5.Connection position:Centred, rear.

6.Color:black.

Technical Data

Indicating range	0 MPa ... 1 MPa
Symbol	00991463
Conforms to standard	EN 837-1
Nominal size of pressure gauge	40
Design	Bourdon tube pressure gauge
Type of mounting	Front panel mounting
Operating medium	Inert gases Neutral fluids
Operating pressure	0 MPa ... 1 MPa
Operating pressure	0 psi ... 145 psi
Degree of protection	IP43
Storage temperature	-40°C-70°C
Media temperature	-20°C-60°C
Ambient temperature	-20°C-60°C
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Note on materials	RoHS-compliant
Position of connection	Centred, rear side
Pneumatic connection	G1/4
Material in contact with the medium	Brass
Material screw-in stud	Brass
Material housing	ABS
Material screen	SAN
Material mounting ring	Steel
Material screws	Steel
Housing colour	Black
Product weight	80 g
Note on operating and pilot medium	No acetylene No oxygen

Package picture

ABS Flanged Pressure Gauge PAGN-P-40-1M-G14 8037006 GTIN4052568430160

Datasheet

There are many models . Please hurry to me!
